Wednesday March 16, 2011

Attendees: Ron Williams, Bob Erickson, Robert Garner, Stan Paddock, Bill Flora, Frank King, Don Luke, Douglas Martin, Bill Newman, Joe Preston, Ed Thelen, Allen Palmer, Ron Crane, Judith Haemmerle

Visitors: Johann Gunnarsson, Stephen Somerstien and several lost Computer History Museum visitors.

Johann Gunnarsson is the leading long distance visitor to the CHM IBM 1401 Restoration room. He lives in Iceland and in the 1960s maintained all of the IBM 1401 computers in Iceland. (2)

Johann Gunnarsson’s son Jóhann Jóhannsson was fascinated with the IBM 1401 and wrote a musical piece "IBM 1401 A User's Manual". This was played on one of the IBM 1401s before it was shut down for the last time. An interesting piece can be seen on http://www.youtube.com/watch?v=whvzDJGt-fk.

A sample of our own IBM 1401 playing music can be heard at: http://www.paddockdrayage.com/IBM1401PlayingMusic.wmv.

Robert Garner and Johann Gunnarsson are shown above in the IBM 1401 Restoration Room at CHM.

To make Tape Drive Three on the German IBM 1401 work right, you have to get right down to the internal problems. That is what Joe Preston is doing above.

Ed Thelen and Bob Erickson continue to work on the IBM Model B typewriter. Why Ed thinks you need a big Tektronix oscilloscope for this mechanical device, I have no idea.

Robert Garner, Ron Williams and Bill Flora have found something funny to laugh about. The Connecticut 1402 still has a lingering problem with the card reader so that must not be it.

Stan Paddock

Saturday, March 12, 2011

Attendees: Ron Williams, Bob Erickson,  Stan Paddock,  Judith Haemmerle

Due to technical difficulties, the video portion of this blob continues to be interrupted.

Ron Williams and Stan Paddock continue to work on the Connecticut 1402 card reader. We are getting closer but have not found the cause of the problem.

Bob Erickson and Judith Haemmerle continue their work on the IBM Model 'B' transmitting typewriter. Almost all of the keys will cause the type bars to strike the paper and leave a good impression.

Stan Paddock

Wednesday March 09, 2011

Attendees: Ron Williams, Bob Erickson, Robert Garner, George Ahearn, Stan Paddock,  Frank King,  Douglas Martin, Bill Newman, Joe Preston, Ed Thelen, Allen Palmer, Ron Crane, Judith Haemmerle

Due to technical difficulties, the video portion of this blob has been interrupted.

While pictures were taken on March 9th, the camera used to take the pictures has decided to hide. Anyone knowing the whereabouts of the silver Kodak camera is urged to notify your local police department.

Allen Palmer and Joe Preston continue their work on tape drives number two and three of the German IBM 1401 system.

Bob Edwards and   Judith Haemmerle continue their work on the IBM Model 'B' Transmitting typewriter.

Ron Williams continue on the read problems associated with the Connecticut IBM 1401 system. Every other card that has an odd number of rows punched will be flagged as an error. For those of you that know IBM 1401 systems, this is a error associated with the 'X' check memory plane.

Ron Crane and Stan Paddock continue to work on the power input to the German IBM 1401 system. The power distribution was as follows.

German IBM 1401, 1402, 1403, 1406, (1) 729	220/380 3Ǿ 50 Cycles	10.85	2,387.00	53.06%
	220/380 3Ǿ 50 Cycles	7.05	1,551.00	34.47%
	220/380 3Ǿ 50 Cycles	2.55	561.00	12.47%
Total of three phases		20.45	4,499.00	100.00%

Ron investigated and found the fans (35) were all powered from lea 'A'.
We moved the fan load from leg 'A' to leg 'C'. The power distribution is now as follows:

German IBM 1401, 1402, 1403, 1406, (1) 729	220/380 3Ǿ 50 Cycles	6.80	1,496.00	32.03%
	220/380 3Ǿ 50 Cycles	7.01	1,542.20	33.02%
	220/380 3Ǿ 50 Cycles	7.42	1,632.40	34.95%
Total of three phases		21.23	4,670.60	100.00%

It does not get any better than that.
Now that the legs are balanced, we will work on the power factor. With the leg load and power factor controlled, the loading on the Pacific power converter will be much lower.
During our tests, we found that two of the linear amplifiers in the converter are not performing up to their full ratings. These will be fixed or replaced from our spares.


With an invitation from Karen Kroslowitz, Bill Newman and Doug Martin visited the CHM warehouse in Milpitas. They were looking for some interconnecting cables for the IBM Model 'B' Transmitting typewriter. Two matching typewriters were found but they were both associated with the stored IBM 1620. While they were offered to us because they were already 'service' status, Bill and Dough did not want impact a future revival of the 1620.

There is a section of the Connecticut IBM 1402 that has been missing since we received the machine. While it is not required for the functioning of the machine, it does expose some electrical and mechanical dangers to the operators.

We removed the missing pieces from the German IBM 1402 and Bill and Doug took them with them to the warehouse to see if any of the stored IBM card machines matched what we need.

The guys found several close calls but only the IBM 1402 from Visible storage had the right parts. These are not available to us as it is a part of the permanent collection.

We had three couples who found there way down the hall and wondered what was going on in the 1401 Restoration room. They got the usual "Data Processing in the 1960s" dog and pony show. They seemed to enjoy it as much as I enjoy giving it.



Saturday, March 05, 2011

Attendees: Ron Crane and Stan Paddock.

Ron Crane and I have been working on the strange power consumption for the German IBM 1401.
Ron called me up this morning and asked if I would like to come in today when we would not bother anyone else. I said yes.

What we learned:

1. Both the Connecticut and German machines have 4 Ferro-resonance transformers. 2 in the 1402, 1 in the 1401 and one in the 1406.
2. The Connecticut machine runs on three phase 120/208 60 HZ power.
3. The Connecticut machine runs the Ferro-resonance transformers by connecting them between two legs of the input power. (208 volts)
4. The German machine runs on three phase 280/380 50 HZ power. To minimize the input voltage to the Ferro-resonance transformers, the Ferro-resonance transformers are connected from a leg of the input power to neutral. This supplies each one 220 V instead of 380 V if they were connected leg to leg like the Connecticut machine.
5. If we determine the power of each Ferro-resonance transformer, we could switch the source to one or more and thereby balance the total load to the German machine.
6. We also have to determine how the inputs to the Ferro-resonance transformers map back to the input power.

Stan Paddock

Wednesday March 02, 2011

Attendees: Ron Williams, Bob Erickson, Robert Garner, George Ahearn, Stan Paddock,  Frank King, Don Luke, Douglas Martin, Bill Newman, Joe Preston, Ed Thelen, Allen Palmer, Ron Crane, Judith Haemmerle

Guest: Bill Kell; My Father-in-law from Carson City, NV

 Having spent most of his career making computers and other electronics work, Bill had little trouble punching his name into a punched card on one of our 026 Keypunches.

Bill had a discussion with Doug Martin only to find out that they both spent considerable time doing support at the same over seas site.

It was a tape drive day. Allen Palmer continues on fixing the brake on the second IBM 729 for the German system

Joe Preston continues to work on the third IBM 729 for the German system. Joe has taken this machine from totally dead to being able to load a tape and I saw it writing data. Now if that data was good data ..........

Frank likes the IBM 1403 printer. When he heard a bad bearing in the IBM 1403 connected to the Connecticut system, he tore into it to get to the bad bearing. That is when he determined the bearing noise came from the IBM 729 directly behind the printer.  Frank found the offending bearings and is in the process of replacing the bearings with new bearings.

Ron Crane continues his quest to make the input power correct to the German machine.

While checking power supplies, Ron found the comment above written inside one of the gates. We are going to the CHM staff for a translation.

In our quest to find all of the problems with the Connecticut IBM 1402 card reader, we found one of the transistors  was weak. We found a match on E-Bay and bought it. The picture above is Bill Newman installing the transistor inside the bowels of the 1402. We have fixed several bugs in this area but still have at least one more to go.

Judith Haemmerle and Bob Erickson are working on the IBM Model 'B' transmitting typewriter that will be attached to the Connecticut system as an IBM 1407 inquiry station.


Stan Paddock
